PB LIFT S195-12ES Electric, 19.6m Working Height, 700

Omschrijving

Manufacturer: PB Lift
Typ: S195-12ES
Manuf. Year: 2015
Working Hours: Not Displayed
Serial nr: 121951124

Working height: 19.60 m
Lift capacity: 700 kg
Lift capacity platform extension: 700 kg

Platform extension (scissors): 1.50 m
Gradeability: 25 %
Speed - stowed: 1.44 km/h
Speed - raised: 0.13 km/h
Drive type: Electro-hydraulic drive
Battery capacity: 640 Ah

Area of application: indoor + outdoor
People indoor: 2
People outdoor: 2

Turning radius outside: 4.04 m
Drivable at full height: Yes

Total length: 4.51 m
Total width: 1.22 m
Total height: 3.34 m
Transport height: 2.45 m
Total weight: 9.360 kg

The low weight of 9.360 kg and the possibility to minimize the height to 2.46 m by folding the rails, also facilitate an easy transport.

Via touch of the button the working platform levels thanks to the patented PB support system automatically within a few seconds in an absolute safe position

This scissor lift is also suitable for inner-city operations on common sidewalks and at tight spaces – and this with a working height of 19.60 m

CE (Declaration of Conformity)

More detailed pictures / product movie on our website.

pfeifermachinery.com

Above specifications are subject to change without prior notice and subject to errors.
